Merkel Guide Ring EKF

Installation & Handling

Installation dimensions

Material Properties

Seal Capabilities

Part No. ID OD H1 H2 Quantity Pick
94323 246 250 30.5 30
95594 216 220 30.5 30
99963 196 200 25.4 25
94204 176 180 25.4 25
99862 156 160 25.4 25
94201 146 150 25.4 25
99425 136 140 20.3 20
34301 131 135 20.3 20
99863 126 130 20.3 20
99172 121 125 20.3 20
99740 116 120 20.3 20
94194 111 115 20.3 20
99864 106 110 20.3 20
27257 101 105 20.3 20
99376 96 100 15.2 15
94193 91 95 15.2 15
99426 86 90 15.2 15
99331 81 85 15.2 15
34024 76 80 15.2 15
94192 71 75 15.2 15
99739 66 70 10.2 10
99368 61 65 10.2 10
99861 59 63 10.2 10
99375 56 60 10.2 10
95290 54 58 10.2 10
99424 51 55 10.2 10
99423 46 50 10.2 10
94191 41 45 10.2 10
99422 36 40 8.2 8
1264 31 35 8.2 8
94044 28 32 8.2 8
99665 26 30 8.2 8
99664 21 25 8.2 8
94215 16 20 8.2 8
